Electronic Ink Screen OTP Contactless RFID Card 13.56mHz custom Printed
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | HY |
| Certification: | RoHS authentication/CB authentication |
| Model Number: | A0145 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Single transparent bag, outer carton |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20000PCS |
|
Detail Information |
|||
| Layout Features: | Print Clear Color Standard Color Difference | Coding Method: | Laser Code UV Code Flat Code Spray Code |
|---|---|---|---|
| Working Frequency: | 13.56mHz | Card Body Thickness: | 0.76-1.4mm |
| Capacity: | 128K Bit （customizable） | Seakcard Process: | Cold Pressure Process |
| Highlight: | OTP Contactless RFID Card,13.56mHz Contactless RFID Card,13.56mHz rfid contactless card |
||
Product Description
Electronic Ink Screen OTP Contactless RFID Card 13.56mHz Custom Printed
Non contact smart card combined with electronic ink screen, buttons and OTP
Product introduction: Taking the use of independently developed glue and cold pressure process technology, customizing the thickness of the card at 0.84-3.0mm, the appearance thickness is the same as the ordinary bank card, can realize the ink screen information display, fingerprint operation and multi-bit password button operation function The product can be used in low-power built-in lithium battery regimen to achieve many ways to charge solar charge, wireless charging or magnetic charging. OTP smart card is a secure embedded smart chip card with a separate display. This new smart card brings a new identity authentication security solution that effectively prevents various electronic fraud. A lightweight intelligent payment card contains powerful authentication technology. The same password encryption algorithm is embedded in the banking system and intelligent payment card to ensure that the password is simultaneously generated, and then the one-time password generated by the smart payment card is entered into the payment system in the bank payment interface. The smart payment card has completed the safer password system function on the basis of the ordinary bank card. The appearance is the same as ordinary banks, but the functions are more perfect. Through the application of new smart cards, we believe that users' assets will be safer, and the cost of safe solution is low, easy to use and easy to implement.
| Product parameters | Type | Active / passive |
| Screen | Electronic Paper / Glass / OLED screen | |
| Screen size | 1.54 inch / 2.13 inch Section screen / dot screen | |
| Appearance color | Customizable layout | |
| Thumbprint module | IDEX/FPC | |
| Beacon tips | Led prompt light [ purple, red, blue ] | |
| Interface | 7816 interface (optional) | |
| RFID | 13.56mhz | |
| NFC | Optional | |
| Frequency | High frequency | |
| Operating temperature | -20~70 ℃ | |
| Encapsulation material | PVC ABS PET PETG | |
| Bluetooth | Optional | |
| Waterproof grade | IP68 industrial waterproof | |
| Number of keys | 5 bits / 13 bits | |
| Ultra thin lithium battery | >80mah (as required) | |
| Charging mode | Magnetic suction / wireless charging / solar charging |
PCBA seal process: Package the PCBA into a smart card form, has always been a smart card industry for many years of technical difficulties, and the high temperature melting of the traditional smart card production process has not been able to meet the PCBA cable card, and the high temperature of traditional processes will cause the lithium battery. Component damage and other issues. Traditional thermal laminated compression can't keep up with the needs of the times, leading to cold pressure technology. The cold pressure technology refers to the control of the laminated temperature by the temperature control debugging device through the refrigerator. The debugging device can clearly grasp the temperature change temperature of the internal lithium polymer battery and transmit the instruction to the terminal, thereby effectively controlling the lamination temperature and the layer. Pressure time. Can be widely used in communication, financial payment, object positioning and other fields.
FAQ: Non contact smart card combined with electronic ink screen, buttons and OTP
1. Q: Are you a manufacturer or a trading company?
A: We are manufacturers.
2. Q: Where is your factory? How can I visit there?
A: Our factory is located in Shenzhen, Guangdong Province, China. It takes about 1 hour by train from Hong Kong. Warmly welcome customers at home and abroad to visit us.
3.Q: How is your quality control?
A: Stabilized material supplier of strictly screening before production ensures the quality of the product from the source.
B: Production: Adopt new automatic quality inspection equipment to improve production efficiency, while fast sorting.
C: After production: artificial one strict quality inspection, ensuring 100% pass rate, does not allow the order to flow to the market.
4.Q: What services do you have?
A: We are responsible for all issues we consult to after-sales.
5. Q: How can I get some samples?
A: Please feel free to contact us by email for sample requirements. We are honored to provide you with samples for testing and inspection.
6.Q: What is the shape of the smart card?
A: It can be a standard card L * W: 85.6 * 54mm / shaped card, which can be customized according to requirements.
7.Q: What is the material of the smart card?
A: It can be PVC ABS PET PETG, etc., can be customized according to your needs.
feature
1. The perfect combination of smart cards and OTP, easy to use
2. Support NFC, ISO 7816 and other communication methods
3. Customizen of the People's Bank of China, e-wallet and Java Card 2.2.1, and applications on the Global Platform 2.1.1
4. As a time-based dynamic token that supports TOTP algorithm
5. Electronic display, password is clearly displayed on electronic paper.
6. Power saving, use buttons for 3 years 45,000 times to generate 33000 OTPS.
