1.54 Inch Active OTP Smart Card For Personal Information Card
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | HY |
| Certification: | RoHS authentication/CB authentication |
| Model Number: | A18 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Single transparent bag, outer carton |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20000PCS |
|
Detail Information |
|||
| Hardware Design: | Schematic Diagram And PCB File Drawing | Thickness: | 0.76-1.0mm |
|---|---|---|---|
| Charging Mode: | Magnetic Suction, Wireless Charging, Solar Charging | Waterproof Level: | IP68 |
| Screen: | 1.54 Inch ，1.02inch , 2.13 Inch , 2.7inch(customizable) | Layout Content: | Customer Customization Is Acceptable |
| High Light: | 1.54 Inch OTP Smart Card,Active OTP Smart Card,IP68 OTP Personal Information Card |
||
Product Description
OTP Smart Card: 1.54 Inch Active OTP Smart Card For Personal Information Card
OTP smart cards thinner than 1mm are used for personnel information cards
OTP Smart Card Features:
Using the integrated packaging technology (cold pressing technology), the ultra-thin components and ultra-thin lithium batteries are integrated and packaged. The thickness specification is 0.84mm-1.2mm. The printed content can be customized, and the rechargeable lithium battery can be welded. It is widely used in transaction payment to achieve high security algorithm and ensure capital security.
Product advantages:
OTP smart card has dynamic password code, Bluetooth connection function, higher security payment confirmation, NFC function and inductive payment with mobile card reader.
Usage:
Heyang OTP smart card and its smart card user identity authentication method. For example, a one-time dynamic password, the smart card itself can generate the authentication information required for identity authentication in CNP environment as needed. In addition, new functions are expanded on the OTP smart card, e-ink ink visual screen is added, and confirmation information, personnel information and other contents can be displayed, The screen size can be customized. In addition, the key function is added. Through the connection of Bluetooth chip, you can enter the amount or password.
|
OTP Smart Card Parameters |
OTP Smart Card Type | Active / passive |
| Screen | Electronic Paper / OLED screen | |
| Screen size | 1.02 inch / 2.13 inch Section screen / dot screen | |
| Appearance color | Customizable layout | |
| Thumbprint module | IDEX/FPC | |
| Beacon tips | Led prompt light [white,red,yellow] | |
| Interface | 7816 interface (optional) | |
| RFID | 13.56mhz | |
| NFC | Optional | |
| Bluetooth | Optional | |
| Waterproof grade | IP68 industrial waterproof | |
| Number of keys | 5 bits / 13 bits | |
| Ultra thin lithium battery | >80mah (as required) | |
| Charging mode | Magnetic suction / wireless charging / solar charging |
Technical Process Description:
Independently invented patented technology, developed PCBA integrated packaging process, and successfully encapsulated ultra-thin lithium battery, chip, solar panel, fingerprint module, ink screen and other components into high-end smart card with high performance and high reliability at room temperature.
Our Services
We are not just another me-too supplier, comparing with our competitors, our competitive advantages are:
- Innovative Products.
- Reliable quality.
- Fast delivery.
- Fast customization capability.
- Competitive price.
- Best in class customer services.
